Finger Punch
The Almex Lightweight Finger Punch punches both ends of the belt at the same time, eliminating waste. This fully automatic and pneumatic machine makes finger punching quick and easy. It is suitable for prepping finger and finger-over-finger splices for PVC and polyurethane belts up to 8mm (0.315”) thick and 3 M (118”) wide.
Features and Product Information
Features
- Sturdy subframe
- Automated 230.2 mm (8”) cylinder, steel punching head for straight and angled configurations
- Punching board
- High-speed steel blades
- Two pneumatic cylinder clamps to hold belt in place
- Control panel
- Up to 100 psi air supply
- Unattended operation during punching operation
- Castors for ultimate portability
Product Information
Options:
- Castors
Specifications
2M Fingerpunch
- Width: 2.5 M (98.4”)
- Length: 1 M (39.3”)
- Voltage: 220 1 PH
- Weight: 400 kg (882 Lbs.)
- Max Width: 2 M (79”)
- Speed: 800 mm/minute (31.5”/min.)
- Max thickness: 8 mm (0.315”)
3M Fingerpunch
- Width: 3.5 M (138”)
- Length: 1 M (39.3”)
- Voltage: 220 1 PH
- Weight: 750 kg (1654 Lbs.)
- Max Width: 2 M (79”)
- Speed: 800 mm/minute (31.5”/min.)
- Max thickness: 8 mm (0.315”)
