BLD - Fusion Lagging - Black Large Diamond

Synthetic Rubber
Won't Prematurely harden
Fusion bonding layer technology

BLD - Fusion Lagging - Black Large Diamond Product Sheet

FusionLagg BLD (Black Large Diamond) is a large profile pulley lagging, ideal for drive pulleys with medium tension belt ratings.

Features and Product Information

Features

Made from Synthetic rubber
Exceptional grip and wear resistance
Pressure-cured FusionLagg has significantly longer life than steam-cured lagging
Press cured using high temperature and pressure
Will not prematurely harden
Featuring our Fusion Systems proprietary bonding layer technology significantly enhancing the bond between the lagging and the pulley shell

Product Information

##Properties:
Colour: Black
Elastomer: NR/BR
Tensile Strength: 28.5 Mpa (2700 psi)
Elongation at Break: 500 %
Density: 1.12 g / cm³
Hardness: 60: (±5) Shore A
Abrasion Resistance: 105 mm³
Groove Dimension: 4 mm x 3 mm (3/16” x 1/8”)
Diamond Dimensions: 45 mm x 79 mm (1 13/16” x 3 1/8”)

Specifications

Product Code	Dimensions (Metric)	Dimensions (Imperial)
CFL-BLD-5050	12 mm x 1500 mm x 15.24 M	1/2" x 60" x 50'
CFL-BLD-5050W	12 mm x 2000 mm x 15.24 M	1/2" x 78" x 50'
CFL-BLD-6233	15 mm x 1500 mm x 10 M	5/8" x 60" x 33'
CFL-BLD-6233W	15 mm x 2000 mm x 10 M	5/8" x 78" x 33'
CFL-BLD-6250	15 mm x 1500 mm x 15.24 M	5/8" x 60" x 50'
CFL-BLD-6250W	15 mm x 2000 mm x 15.24 M	5/8" x 78" x 50'
CFL-BLD-7533	19 mm x 1500 mm x 10 M	3/4" x 60" x 33'
CFL-BLD-7533W	19 mm x 2000 mm x 10 M	3/4" x 78" x 33'
CFL-BLD-7550	19 mm x 1500 mm x 15.24 M	3/4" x 60" x 50'
CFL-BLD-7550W	19 mm x 2000 mm x 15.24 M	3/4" x 78" x 50'
